| Highest Voltage for Equipment | Upto 40.5KV (1 min: 10-95KV, BIL: 20-200KV) |
| Main Primary Voltage (Un) | 3; 6; 10;15; 20; 30; 33; 35 KV (phase to earth Un/Ö3) |
| Secondary Voltages | 100; 110; 100/Ö3; 110/Ö3; 100/3; 110/3 |
| Frequency | 50 or 60Hz |
| Rated short-time thermal current (1 sec) | 4; 6.3; 8; 12; 16; 20, 25;31.5; 40; 50; 63; 80; 100 KA |
| Accuracy class: measuring winding | 0.1; 0.2; 0.5; 1 |
| Accuracy of Protecting winding | 3P; 6P |
| Accuracy of auxillary winding | 6P |
| Secondary windings | 2 |
| Mximum r(VA)ated burden | 6000 |
| Secondary Terminals | 8 to 12 |
